Wireless Specifications (Screen Mirroring):
Supported Speed:IEEE 802.11g (2.4GHz): 54 Mbps, IEEE 802.11n (2.4GHz): 130.0 Mbps, IEEE 802.11a (5GHz): 54 Mbps, IEEE 802.11n (5GHz): 270.0 Mbps, IEEE 802.11ac (5GHz): 780Mbps
LCD:
Native Resolution:Full-HDSize:0.61” (1.549 cm)
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system
Screen Size (Projected Distance):
Standard Size:60” (152.4 cm) screen (135 cm – 164 cm)Zoom : Wide:30” to 300” [67 cm to 686 cm]Zoom : Tele:30” to 300” [81 cm to 828 cm]
Brightness2:
Colour Light Output:3,400 lmWhite Light Output:3,400 lm
Contrast Ratio:
Contrast Ratio:16,000:1
Geometric Correction:
Vertical/Horizontal Keystone:±30° / ±30°Auto Keystone:Yes (Vertical)Horizontal Slide Keystone Correction:YesQuick Corner:Yes
Connectivity:
USB Interface:USB Type A: 1 (for USB Memory, USB Document Camera, Firmware Update)
USB Type B 1 (for USB Display, Mouse, K/B, Control, Firmware Update)Network:Wireless LAN: OptionalAnalog Input:D-Sub 15 pin: 1 (Blue)
Composite: 1 (Yellow)Digital Input:HDM: 2 (one of terminal supports MHL)Audio Input:2 RCA (White x 1, Red x 1)Audio Output:Stereo mini x 1Wireless:optional with ELPAP11
Operating Altitude:
Operating Altitude:0 – 3,000 m <0 – 9,843 ft> (over 1500m / 4,921 ft: with high altitude mode)
Start-Up Period:
Start-Up Period:About 6 seconds
Warm-up period: 30 seconds
Direct Power On/Off:
Direct Power On/Off:Yes / Yes
Dimension Excluding Feet (W x H x D):
Dimension Excluding Feet (W x H x D):249 x 302 x 87 mm
Projection Lens:
Type:Optical Zoom (Manual) / Focus (Manual)Focal Length:14.06 mm – 16.82 mmZoom Ratio:1.0-1.35 (Digital Zoom)F-number:1.58 – 1.70Throw Ratio Range:1.02-1.23
Wireless Specifications (Wireless LAN: Built-in):
Supported Speed For Each Mode*3:IEEE 802.11b (2.4GHz): 11 Mbps, IEEE 802.11g (2.4GHz): 54 Mbps, IEEE 802.11n (2.4GHz): 72.2 Mbps, IEEE 802.11a (5GHz): 54 Mbps, IEEE 802.11n (5GHz): 150.0 MbpsWireless LAN Security:Access Point: WPA2-PSK (AES), Infrastructure: WPA2/WPA3-PSK, WPA2/WPA3-EAPSupported Connection Mode:Infrastructure, Access Point
Adjustment Functions:
Aspect Mode:Yes
Image Enhancement:
Detail Enhancement:Yes
Internal Speaker(s):
Sound Output:2W Monaural
